PRODUCT
LF70GY-3
|
SPECIFICATIONS
|
|
|
Motorcycle Model
|
LF70GY-3/LF90GY-3
|
|
Dimension (L×W×H mm)
|
1550×620×950
|
|
Wheelbase (mm)
|
1045
|
|
Net Weight (kg)
|
74
|
|
Seat Height (mm)
|
730
|
|
Fuel Tank Capacity (L)
|
2.0 (main tank), 0.5 (secondary tank)
|
|
Engine Type
|
horizontal single-cylinder, air-cooled, four-stroke
|
|
Bore×Stroke (mm)
|
47×41.4/47×49.5
|
|
Displacement (mL)
|
72/86
|
|
Compression Ratio
|
8.8:1/8.5:1
|
|
Max. Power (kW@rpm)
|
3.8@7500/4.4@7500
|
|
Max. Torque (N.m@rpm)
|
4.8@4500/5.5@4500
|
|
Start
|
electric/kick start
|
|
Transmission
|
4 gears, hand-clutched
|
|
Brake (front/rear)
|
disc or drum/drum
|
|
Wheel
|
Al-alloy or spoke
|
|
Tire (front/rear)
|
3.50-10/3.50-10
|
|
Max. Speed (km/h)
|
60/80
|
|
Economical Fuel Consumption (L/100km)
|
≤1.3/1.5
|
|
SPECIFICATIONS
|
|
|
Motorcycle Model
|
LF70GY-3/LF90GY-3
|
|
Dimension (L×W×H mm)
|
1550×620×950
|
|
Wheelbase (mm)
|
1045
|
|
Net Weight (kg)
|
74
|
|
Seat Height (mm)
|
730
|
|
Fuel Tank Capacity (L)
|
2.0 (main tank), 0.5 (secondary tank)
|
|
Engine Type
|
horizontal single-cylinder, air-cooled, four-stroke
|
|
Bore×Stroke (mm)
|
47×41.4/47×49.5
|
|
Displacement (mL)
|
72/86
|
|
Compression Ratio
|
8.8:1/8.5:1
|
|
Max. Power (kW@rpm)
|
3.8@7500/4.4@7500
|
|
Max. Torque (N.m@rpm)
|
4.8@4500/5.5@4500
|
|
Start
|
electric/kick start
|
|
Transmission
|
4 gears, hand-clutched
|
|
Brake (front/rear)
|
disc or drum/drum
|
|
Wheel
|
Al-alloy or spoke
|
|
Tire (front/rear)
|
3.50-10/3.50-10
|
|
Max. Speed (km/h)
|
60/80
|
|
Economical Fuel Consumption (L/100km)
|
≤1.3/1.5
|
