PRODUCT
SS3-4V
|
SPECIFICATIONS
|
|
|
Motorcycle Model
|
LF200-10M (Four-valve)
|
|
Dimension (L×W×H mm)
|
2000×730×1050
|
|
Wheelbase (mm)
|
1350
|
|
Net Weight (kg)
|
150
|
|
Seat Height (mm)
|
775
|
|
Fuel Tank Capacity (L)
|
12.5
|
|
Engine Type
|
vertical single-cylinder, four-valve, water-cooled, four-stroke
|
|
Bore×Stroke (mm)
|
65.5×58.8
|
|
Displacement (mL)
|
198
|
|
Compression Ratio
|
11.5:1
|
|
Max. Power (kW@rpm)
|
15@9000
|
|
Max. Torque (N.m@rpm)
|
17.5@7500
|
|
Start
|
electric start
|
|
Transmission
|
6 gears, hand-clutched
|
|
Brake (front/rear)
|
disc/disc
|
|
Wheel
|
Al-alloy
|
|
Tire (front/rear)
|
100/80-17/130/70-17
|
|
Max. Speed (km/h)
|
120
|
|
Economical Fuel Consumption (L/100km)
|
≤2.3
|
|
SPECIFICATIONS
|
|
|
Motorcycle Model
|
LF200-10M (Four-valve)
|
|
Dimension (L×W×H mm)
|
2000×730×1050
|
|
Wheelbase (mm)
|
1350
|
|
Net Weight (kg)
|
150
|
|
Seat Height (mm)
|
775
|
|
Fuel Tank Capacity (L)
|
12.5
|
|
Engine Type
|
vertical single-cylinder, four-valve, water-cooled, four-stroke
|
|
Bore×Stroke (mm)
|
65.5×58.8
|
|
Displacement (mL)
|
198
|
|
Compression Ratio
|
11.5:1
|
|
Max. Power (kW@rpm)
|
15@9000
|
|
Max. Torque (N.m@rpm)
|
17.5@7500
|
|
Start
|
electric start
|
|
Transmission
|
6 gears, hand-clutched
|
|
Brake (front/rear)
|
disc/disc
|
|
Wheel
|
Al-alloy
|
|
Tire (front/rear)
|
100/80-17/130/70-17
|
|
Max. Speed (km/h)
|
120
|
|
Economical Fuel Consumption (L/100km)
|
≤2.3
|
